| Features |
- All you have to put the components on the chute and this
machine cuts automatically.
- This machine corresponds to many kinds of components.
- The structure is simple and it's easy to maintain.
- As this machine does not need Air supply,there is no problem
of set-position.
|
| Specifications |
Work pieces Supply |
Operator |
| Machine tact |
1sec./time(Adjustment of straight feedder) |
| Power |
AC100V 50/60Hz |
| Machine size |
Approx.250(W)×285(D)×295(H)mm |
| Weight |
Approx.17kg |
| Work pieces handled |
Radial Bulk Components
Work thickness MAX.45mm
Work length Arbitrary
Work height MAX.25mm
Lead length MAX.40mm |
| Cut measure |
Work below 3.0 to 10.0mm(Changeable type) |
| Cut ability |
Max.Φ1.2mm×3(Soft copper wires) |
