| Features |
- Sealed sections remain in stabilized condition. This machine
features high rigidity and easily set sealing conditions.
- Tape replacement can be conducted with ease. Apertures and
grade differences between guides have been eliminated.
- The manual feed space has been widened and obstacles removed.
- Tape feed operation can be automated. Room is provided for
auto-loaders.
|
| Specifications |
Taping method |
Embossed taping |
| Widths of tape used |
56, 44, 32, 24, 16 (8, 10, 24) mm. |
| Reel diameter |
Φ400 max. |
| Feeding of tape |
Tape is fed using a stepping motor. |
| Direction of tape movement |
Right to left |
| Taping speed |
60 work pieces/min. (depending on operator's skills and
condition of tape) |
| Method of changing tape width |
Replacing tape and heater blocks;
Adjusting width of tape feed guide
sprockets; setting tape footage counter;
and adjusting width of guide rails. |
| Drive of sealing head |
Air-driven |
| Sealing temperature |
From room temperature up to 200°c. |
| Detection of missing teeth |
Optical sensor-detected. |
| Detection of loose teeth |
Optical sensor-detected. |
| Detection of floating |
|
Driving power source
|
AC 100 |
|
Pneumatic pressure
|
0.4 MPa |
|
| Counters used |
One (1) 6-digit blank seal counter
One (1) 6-digit taped number counter |
| Method of control |
Microcomputer-controlled |
| Machine dimensions (desk-top type) |
Width: 1250 mm
Depth: 300 mm
Height: 500 mm |
(Machine stand is optional.) |
|
| Color |
Cream |
