| Features |
- This machine is easy to operate.
- Thouth you usually cut at pre-station, usuing this machine
,you can quickly cut and insert in PBC.
- As this machine has simple mechanism, maintenance is easy.
- As this machine does not need Air supply, there is no problem
of set-position.
|
| Specifications |
Machine size |
Approx.100(W)×190(D)×95(H)mm |
| Weight |
Approx.3.5kg |
| Power |
AC100V 50/60Hz |
| Cut ability |
Max.φ0.8mm×8(Soft copper wires) |
| Machine tact |
1sec./time |
| Cut measure |
Work below 2.0 to 10.5mm(Changeable type) |
| Work pieces handled |
Radially taped component parts |
| Cutter width |
50mm(Lead pitch effective range48mm)
|
