| Features |
- This machine is easy to operate.
- Thouth you usually cut at pre-station, usuing this machine
,you can quickly cut and insert in PBC.
- As this machine has simple mechanism, maintenance is
easy.
- As this machine does not need Air supply, there is no
problem of set-position.
|
| Specifications |
Machine size |
Approx.100(W)×150(D)×90(H)mm |
| Weight |
Approx.2kg |
| Power |
AC100V 50/60Hz |
| Cut ability |
Max.Φ8mm×2(Soft copper wires) |
| Machine tact |
1sec./time |
| Cut measure |
Work below 3.0 to 12.0mm(Changeable type) |
| Work pieces handled |
Radially taped component parts |
| Cutter width |
25mm(Lead pitch effective range23mm)
|
